Ⅰ Product application -- UHF RFID washing label RI-X011 60*20mm
Name: UHF RFID washing label RI-X011 60*20mm
* Operation automation in the laundry process
* Improve the accuracy of information between the laundromat and its customers
* Hospital uniform and hotel bed linen tracking
* Large enterprise service attendance management
* Operation automation in the laundry process
* Improve the accuracy of information between the laundromat and its customers
* Hospital uniform and hotel bed linen tracking
* Large enterprise service attendance management
Ⅱ Main features -- UHF RFID washing label RI-X011 60*20mm
* Sizes available for different needs
* Excellent read performance
* Good chemical resistance
* Excellent mechanical pressure resistance
Ⅲ Optional standard bag - UHF RFID washing label RI-X011 60*20mm
* Material: All polyester
* Size: customized according to your needs
* Up to 4 kinds of colored embroidery
Ⅳ Technical parameters -- UHF RFID washing label RI-X011 60*20mm
| Electrical features | |
| Inner chip | NXP U CODE 7, NXP U CODE 7m ( EPC Class 1 Gen 2 / ISO 18000-6C compliant) |
| Capacity | * NXP U CODE 7: 128 bits EPC, no user memory * NXP U CODE 7m:128 bits EPC, 32 bits user memory |
| Operating frequency | 902~928 MHz |
| Reading distance | Stationary reader: 60*20mm: 5.5m (18 feet) Handheld reader: 60*20mm: 4m (13 feet) |
| *The final reading range depends on the rfid reading device and application environment. | |
| Physical features | |
| Model | RI-X011 60*20mm |
| Dimensions | 60*20mm |
| Material | 50% cotton, 50% terylene |
| Operating temperature | -40~ 85℃ (-40~185℉) |
| Storage temperature | -40~120℃ (-40~248℉), 50% RH |
| Useful life | 200 washes |
| Wash cycle performance | |
| Extreme temperature | 220℃ (428℉), 30s, 2.5 bars |
| Tunnel washing | 100℃ (212℉), 60mins, 120 bars |
| Tumble drying | 160℃ (320℉), 30mins |
| Tunnel ironing | 185℃ (365℉), 30mins |
| Sterilization process | 134℃ (273.2℉), 20mins, RH 85% |
| Dehydrator pressure | 120bars |
| Corrosion resistance | Washable resistance to all common chemicals |
Ⅴ Product display -- UHF RFID washing label RI-X011 60*20mm
Real-shot display
