I Chip features——Pallet / Transfer box / Carrier RFID tag ZJ8654
Name: Pallet / Transfer / Carrier RFID tag ZJ8654
-Complies with EPC Gen2 (V1.2.0) and ISO/IEC18000-6C standards-Globally universal label: operating frequency is 860MHz-960MHz
-800-bit non-volatile memory
-96-bit EPC
-512-bit User Memory
-64-bit unique TID (cannot be rewritten)
-32-bit access and lockout passwords
-Pre-programmed with a unique and unchangeable 64-bit serial number
-User storage can be managed in 64-bit blocks, and can be continuously locked and protected by an access password
-Supports all mandatory and optional commands, including item-level commands
-Has customized commands for high-speed data writing, and can write the EPC codes of 30 labels per second
-Low-power reading and writing operations
-Excellent operating distance, which can reach up to 10 meters with a suitable antenna
II Technical parameters——Pallet / Transfer box / Carrier RFID tag ZJ8654
Optional chip: H9/U9
Antenna dimensions: 70*17mm
Product dimensions: 86mm*54mm
Adhesive backing: 3M
Reading distance: 8 meters for handheld terminals, 15 meters for 12DBI integrated interrogators
Communication protocol: ISO18000-6C
Operating frequency: 860-960MHz
Storage capacity: 512Bits
Reading and writing times: ≥ 100,000 times
Data retention: ≥ ten years
Optional fabric: None
Operating temperature: -20℃-65℃
III Product display——Pallet / Transfer box / Carrier RFID tag ZJ8654
