I Chip features -- Dry inlay high frequency Ntag 213 diameter 21mm
- Contactless energy and data transmission
- Working efficiency 13.56MHz
- Data transmission rate is 106kbit/s
- Data integrity is 16-bit CRC, parity check, bit coding, bit counting
- Working distance up to 100 mm (depending on various parameters such as field strength and antenna geometry)
-7 byte serial number (according to ISO/IEC14443-3 protocol)
- UID ASCⅡ image for automatic serialization of NDEF messages
- Trigger an automatic NFC counter when reading a command
The FAST READ feature allows scanning full NDEF messages with a single fast-read command, reducing overhead in high-throughput production environments
- Working efficiency 13.56MHz
- Data transmission rate is 106kbit/s
- Data integrity is 16-bit CRC, parity check, bit coding, bit counting
- Working distance up to 100 mm (depending on various parameters such as field strength and antenna geometry)
-7 byte serial number (according to ISO/IEC14443-3 protocol)
- UID ASCⅡ image for automatic serialization of NDEF messages
- Trigger an automatic NFC counter when reading a command
The FAST READ feature allows scanning full NDEF messages with a single fast-read command, reducing overhead in high-throughput production environments
II Technical parameters -- Dry inlay high frequency Ntag 213 diameter 21mm
Name: Dry inlay High Frequency Ntag 213 diameter 21mm
Optional chip: NTAG213
Antenna size: Φ21mm
Label size: None
Communication protocol: ISO14443A
Operating frequency: 13.56MHz
Storage capacity: 144byte
Read and write times: ≥ 100,000 times
Data retention: ≥10 years
Optional fabric: None
Operating temperature: -10℃-65℃
III Products -- Dry inlay High frequency Ntag 213 diameter 21mm
1.Sectional display
2.Real-shot display
IV Antenna display - Dry inlay high frequency Ntag 213 diameter 21mm
Ⅴ Production process - Dry inlay High frequency Ntag 213 diameter 21mm
